Maha – 2 Cylinder lifts ZS SQUARE II 3.5 FT

SQUARE | Two Post Inground Lift with flat support bridge and 3500 kg load capacity

Description:

Flat support bridge (FT) hot-dip galvanised:

Easier, tyre-preserving drive-on thanks to all-round bevelled pull-out elements combined with low construction height with rubber mounting plate (construction height no more than approx. 60 mm)
Large mounting areas thanks to interchangeable mounting plate system cover the entire vehicle spectrum
Flexible and optional range of mounting plates in versions ‘longer – wider – lower’ guarantee optimum mounting of all current and future vehicle models
Rubber support plate enables time-saving direct hold
Optional floor-level installation available for improved lifting platform mount drive-on
Pinch point protection thanks to CE stop rather than foot guard

SQUARE lift unit:

Ample freedom of movement below the lifting platform thanks to the compact post-lifting unit and resulting optimum lighting below the raised vehicle
Outstanding rigidity and optimum safety thanks to torsion-resistant square post
Very quiet pump and very quiet electric motor in corrosion-proof oil-submerged design, optionally with bio oil
Electronic lift control with no-contact, wear-free limit switches and visual error display
Very smooth running due to special long-life nickel coating on posts that promotes sliding, with robust,low-maintenance post design
Protected internal hydraulic safety cylinder guarantee lengthy service life
Mobile synchronisation and safety yoke for careful distribution of force in the post guide as standard
High lifting/lowering speeds are guaranteed (max. 30/20 s)
Battery-operated emergency lowering
Optimisation of workplace ergonomics mentioned thanks to optional, standard-independent control via traffic-light energy module or flush-mounted switching system

Standard Delivery:

Flat support bridge hot-dip galvanised
Lift unit with movable yoke
Wiring and mounting material
Installation box/installation frame not included in delivery
Emergency DOWN cable for connection to switch box
Control unit with 2 x 10 m control cables (flexible oil cables)
Lockable master switch
Operating manual and test log
EC Declaration of Conformity CE
