Maha – 2 Cylinder lifts ZS VARIO 3.5 FT

VARIO | Two Post Inground Lift with flat support bridge and 3500 kg load capacity


Driving platform:

Driving platform length 4400 mm ideal for cars and small transporters
Ample freedom of movement in the working area below the lifting platform thanks to the compact post-lifting unit and resulting optimum lighting below the raised vehicle in particular

Flexible lift with maximum application range thanks torapid lifting of the vehicle with the main driving platforms in vehicle check-in, also for repair or for inspection work, optionally wheel-free lifting by means of swing arm support standard up to 600 mm lifting distance or optionally with full extension up to 2000 mm
Driving on to lift made easier and gentle on tyres thanks to extensions chamfered all the way round combined with low overall height with rubber support plate (only approx. 60 mm)
Best possible vehicle spectrum thanks to very large support area resulting from exchangeable support plate system
Flexible, optional assortment of support plates “longer – wider – flatter” provide optimum support of various vehicle types and for future vehicle generations
A high-quality powder-coated platform covering assists in corrosion protection and adds a significant upgrade in terms of appearance
Optional driving platform coating with granulate coating or Aluminium panelling
Pre-integrated compressed air connection and optional 230V/1PH energy supply in runways
Various assembly variants for optimum use withdriving platform resting on floor with low drive-on height and platform movement area with no tripping hazard edges
driving platforms flush with floor to facilitate driving onto the lift, no protruding assemblies in the lift area
driving platforms flush with floor to facilitate driving onto the lift, no protruding assemblies in the lift area with complete floor levelling of the platform movement area with no tripping hazard edges
Driving platform and floor levelling pre-equipped for use of an optional axle lift
Additional corrosion protection treatment in area of fold and cavity sealing
Optional no-dazzle rotatable LED lighting
Pinch point and shear point protection thanks to CE stop

Lift unit:

A corrosion-resistant, hard-chrome plated hydraulic piston ensures long-term stability since this is immersed in hydraulic oil with every lift, thus ensuring the application of a latent protective film.
Simple, suspended installation of the lifting platform – offering the advantage of power transmission directly into the hall floor
Ultra-quiet hydraulic pump and electric motor, corrosion-resistant oil-submerged version, optionally available with organic oil
Electronic lift control with visual error display
Battery-operated emergency lowering
Optimisation of every aspect of workplace ergonomics thanks to optional, standard-independent control via traffic-light energy module or flush-mounted switching system

Standard Delivery:

Driving platform 4400 mm powder-coated gentian blue (RAL 5010)
Wheel-free jack flat support bridge hot-dip galvanised
Lift unit with integrated after-lift device
Ramps and drive-on plates
Rapid-action compressed-air coupling mounted on driving platform
Wiring and mounting material
Installation box/installation frame not included in delivery
Emergency DOWN cable for connection to switch box
Control unit with 4 x 10 m control cables (flexible oil cables)
Lockable master switch
Operating manual and test log
EC Declaration of Conformity CE
