Maha – ES 93 X

BARLIFT | One Post Inground Lift with X-support and 3000 kg load capacity


X-swing arm support:

Free and unrestricted access to the vehicle during work in the sill and engine area
Swivel arm mount with infinitely extendible, 2-part support arms guarantees the utmost flexibility
Quick and precise uptake of the vehicles with height-adjustable turning plates with thread and plug-in system
Lifting increases and positive-locking vehicle uptake for safe vehicle fixation included in scope of delivery
Automatic support arm locking particularly convenient for manual readjustment of the support arm in the raised set-up state accessible from above
Ample freedom of movement in the working area below the lifting platform thanks to the compact post-lifting unit and resulting optimum lighting below the raised vehicle

BARLIFT lifting unit:

Ultra-quiet hydraulic pump and electric motor, corrosion-resistant oil-submerged version, optionally available with organic oil
Fully electronic lifting platform control unit with assisting visual operating status display
Robust, hard chrome-plated lifting unit with rotation lock
Corrosion-resistant hydraulic piston ensures long-term stability since this is immersed in hydraulic oil with every lift, thus ensuring the application of a latent protective film.
Hydraulic unit integrated in the cassette (standard), may also be installed outside and thereby protected in the dry area where necessary
Installation in all existing MAHA individual cassettes up to a max. of 5500 kg load-bearing capacity also possible
Simple, suspended lifting platform installation, offering the advantage of power transmission directly into the hall floor
Optimisation of every aspect of workplace ergonomics thanks to optional, standard-independent control via traffic-light energy module or flush-mounted switching system
Pinch point safeguards by means of CE stop instead of foot guard
Battery-operated emergency lowering

Standard Delivery:

Swing arm support (X) X-support Carrier: powder-coated anthracite grey (RAL 7016), swing arm extensions galvanised
Support plate and support increase 50 mm
Lifting unit with hydraulic power unit
Cable and mounting materials
Installation box / installation frame not included in scope of delivery
Emergency DOWN cable for connection to the control box
Control unit with 2 x 10 m control cable (Ölflex cable)
Lockable main switch
Operating manual and inspection log book
EC Declaration of Conformity CE
