JohnBean – 800P

Car Wheel Balancer with Touchscreen Monitor and Non-Contact Data Entry


The wheel balancer for garages, car dealerships, tyre shops and premium workshops with high tyre service volume. With touchscreen monitor, automatic non-contact data entry and easyWeight pinpoint indicator light – An accurate, fast and easy solution to position adhesive weights on the wheel.


High-productivity wheel balancer
Rim scanner for
– automatic non-contact rim profiling
– automatic selection of balancing mode and weight position
– automatic acquisition of rim diameter and offset
Smart Sonar for automatic non-contact acquisition of rim width
Touchscreen monitor with graphical user interface PLATINUM – fast and very intuitive
easyWeight: fast pinpoint bottom weight placement. Pinpoint laser light indicator to accurately position adhesive weights on the wheel
Torque-controlled Power Clamp device – fast and accurate clamping of the wheel
Stop-in-Position feature where the operator only has to touch the amount of unbalance on the screen and the wheel is automatically indexed to correction position
QuickBal for reduced measurement time:
Short start-stop cycle time: 4.5 seconds (15’’ rim)
VPM measurement technique for uncompromised accuracy
Rim lighting to facilitate rim cleaning and speed up data entry and weight positioning
Imbalance minimisation and optimisation programs
Networking capability with the optional networking software
Compatible with asanetwork
Print-out with optional printer

Oversize shaft

The 225 mm length allows the use of stud-hole flanges and other accessories for almost every type of rim.


Pinpoint laser identifies exact weight placement location for increased accuracy and efficiency.

Gauge arm

Semi-automatic data entry and positioning of adhesive weights

Split weight mode

Hides adhesive weights behind two adjacent spokes so they cannot be seen from the outside.


Touch the rim with the gauge arm to enter the rim dimensions and automatically select the weight balancing mode.

Power Clamp™

Patented automatic Power Clamp™ electromechanical clamps the wheel accurately with a constant force, reducing the opportunity for chasing weight.


30% reduced cycle time, less than 4,5 seconds, maintaining the same high accuracy.

Smart Sonar™

Automatic, non-contact rim width acquisition delivers greater accuracy and ease of use for a 30% savings in complete process when compared to manual operation.

VPM technique

Measurement system for high precision and repeatability.


It is a tool that allows equipment to be connected to a garage.
With the asanetwork all relevant information are made available at every workstation in the shop as all machines are connected to the commercial software.

PLATINUM interface

Highly intuitive and fast touch-screen monitor with large digits, coloured weight position indicators and PLATINUM user interface – improved intuitiveness and ergonomics.

Rim scanner

The rim scanner automatically detects rim diameter and offset as well as the number and position of rim spokes. Then it automatically chooses balancing mode, weight types and weight positions.

Wheel guard

The patented and ergonomic telescopic wheel guard reduces the footprint.
