JohnBean – V1200


3D-On-the-Car Wheel Aligner


True 3D car wheel aligner for general repair shops and smaller independent garages that want professional quality, simple installation, ease of use

True 3D on-the-car wheel alignment technology with 2 rear camera pods with AC700 wheel clamps, 2 front targets with AC700 wheel clamps and 2 lift-mounted reference pods

3D vehicle measurement provides accurate and live alignment adjustment, full vehicle dimensions, and easy installation requiring no lift calibration
Cordless design with WiFi both for alignment components and for connection to the internet
Graphics display provides all relevant data – optimised for visibility and clarity
Mobile control terminal with 22” monitor, printer and battery chargers for pod batteries
New easy rolling run-out compensation has short roll that stays on the turntable
New information preview provides critical data before work begins – time-saving, ergonomic and easy to understand
Live alignment error checking with compensate, warn, alert notification system to notify the user of errors as they happen without slowing the process
Dynamic ride height and frame angle based vehicle specs
VODI (visual indicators) on the pods guides the technician through the measuring process

Live adjustment of camber, caster, and toe (elevated)
Measurement of toe-out on turns and manual ride height measurement
EZ Toe® allows adjustment without steering wheel holder or at maximum steering angle, prevents crooked steering wheels and simplifies adjustment
Automatic online specification and software update

Manufacturer’s website : JohnBean

Product website : JohnBean-V1200

Product PDF : 9702930_V1200_F
