Consul – Scissor lift Z 8135 DS

Z-Line double scissor lift type Z8135 DS

Product description :

Mobile and stationary applicable: Ultra flat scissor lift with a drive over height of only approx. 100 mm, excl. mobile set, elastomer adapters (20 mm).


Platforms made from slip-resistant bulp plate (optionally hot-dip galv.)
Integrated electro hydraulic drive
Dual hydraulic system – double cylinder in every scissor, no air supply necessary
Safety signal tone during lowering in foot area
Dead-man control via reverse contactor control
With emergency lowering device and overload protection
Tracks adjustable in length with flap mechanism, can be operated from the side
Base frame hot-dip galvanized and galvanized ramps
Incl. 4 elastomer adapters 20 mm
Mechanical synchronisation
Optional: mobile set (1 connecting rod, 2 mountable guide rollers)
Protection class IP54, GS-approved, DIN EN 1493, CE-approved
Hydraulic track synchronisation with cylinder tracking principle- No mechanical connection between the tracks- All articulation points are equipped with grease bolts- Installation on the ground possible without additional accessories
